TRA78097-4 BLUEX XRT Ultimate 4x4 8S Brushless Monster Truck (Traxxas)

Home / TRA78097-4 BLUEX XRT Ultimate 4x4 8S Brushless Monster Truck

TRA78097-4 BLUEX XRT Ultimate 4x4 8S Brushless Monster Truck

$1,349.95 Excl. tax

*AFFIRM Finance Offer Available on Total Purchases of $149 or More

Delivery time: In Store Pick-Up Only

Part Number:	TRA78097-4 BLUEX
Quantity In Stock:	1

TRA78097-4 BLUEX XRT Ultimate 4x4 8S Brushless Monster Truck

High-Performance Aluminum Upgrades

6061-T6 aluminum C-hubs
6061-T6 aluminum steering blocks
6061-T6 aluminum rear hub carriers
6061-T6 aluminum differential housings
6061-T6 aluminum motor mounts

VXL-8s Waterproof Electronic Speed Control

Aggressive tune for more power at any RPM
Integrated cooling fan
3-LED status indicators
Machined heat sink
Powered accessory ports
10-gauge silicone wire
Integrated protection circuits

Velineon 1200XL Brushless Motor

4-pole 1275 Kv
5 mm output shaft
Oversize aluminum heatsink for improved cooling
Dual cooling fans

Up to 60+ mph with Two 4s LiPo Batteries (sold separately)
Traxxas Stability Management

Improves straight line acceleration and braking on low-traction surfaces
Never dulls throttle or slows the truck
Adjusts from off to 100% assistance from the transmitter

TQi 2.4 GHz 2-Channel Radio System with Factory-Installed Wireless Module

Factory-installed telemetry sensors
5-channel micro receiver (6533) with fail-safe security and integrated telemetry ports
Patented waterproof receiver box with easy-access plug

X-Truck Spec 8s Driveline

Machined, hardened steel pinion and spur gear
Full-time shaft-driven 4-wheel drive
Heavy-duty steel CV driveshafts with laser etching
Beefed-up steel differential output cups
Splined aluminum center driveshaft
Machined aluminum stub axles

Transmission

Mod-1 pinion and spur gears
Torque-Biasing Center Drive

Maxx-Spec Differentials

Heavy-duty sealed 4-gear design
Large scale steel ring and pinion gears
Splined outdrives attached with external thru-bolt method
New bulkhead and covers increase bearing support

Rock-Solid Motor Mounting System

Rigid aluminum motor mounts
Precise preset gear mesh adjustments
4 keyed pins lock the motor in place
Motor retention separate from gear mesh

GTX Aluminum Race Shocks

Machined aluminum threaded body
Extra-large bore and capacity
Ultra-smooth TiN-coated 5.2 mm damper shafts
Lower seal cartridge includes integrated wiper seal combination
Aluminum upper spring retainers
Aluminum shock caps with pivot balls
Lower spring perches bolted on

WideMaxx Suspension

Extra-wide suspension arms

Made from our strongest cold-weather material

Double-shear connections
High-strength steel suspension pins with retainers
4 mm machined pivot balls
TUBES 7075-T6 Aluminum front toe links
Oversized wheel bearings

Steering

6061-T6 aluminum steering bellcranks
2085RL high-output metal-gear steering servo

650 oz-in torque at 6.0 volts
0.13 sec/60° at 6.0 volts

Double-shear aluminum servo horn
Heavy-duty servo saver spring
Dirt evacuation channels

Ultra-Low-CG Chassis Design

Modular chassis with interlocking bulkheads

Low center of gravity for improved handling
Flat bottom design
Heavy-duty interlocking skid plates
High-strength buttressing on shock towers

Dual snap-lock battery compartments

Protects batteries from side impacts
Allows secondary battery-clip security

Interlocking components for tight tolerances

ProGraphix Clipless Body

Snaps in place in just seconds
Secure body latches are easy to use
Clipless body mounting system
Rigid internal frame
Dual high-capacity cooling ducts
Molded body reinforcements for tear-through protection
Protective top skids
Rugged high-downforce rear wing

Heavy-duty Bumpers

Reinforced front bumper and rear wing support

Absorb impact forces while retaining shape

Heavy-duty front bumper and support
Reinforced rear wing support
Nerf bars for side impact resistance
Heavy-duty wheelie bar with carry handle

Wheels and Tires

7.4″ Gravix belted race tires

Belted carcass virtually eliminates ballooning at high speed
Low sidewall for sharp turn-in response
Runs quieter than traditional off-road tires

3.8″ matte black XRT race wheels
High-strength glue and bead design
Huge 24 mm splined wheel hubs

Sealed Ball Bearings
Hex hardware with Rust-Resistant Black Oxide Coating

MODEL 78097-4: XRT^® Ultimate: Maxx-Scale 4X4 8s race truck, fully assembled, Ready-To-Race^®, with TQi™ 2.4 GHz radio system, VXL-8s™ brushless power system, and ProGraphix^® clipless body.

What’s In The Box:

XRT Ultimate 8s race truck
VXL-8s waterproof electronic speed control with integrated telemetry
Quick Start Guide
TQi 2.4 GHz radio system
High quality maintenance tools

What You’ll Need:

LiPo Batteries
Traxxas recommends dual 4-Cell, 6700 mAh Power Cell LiPo batteries (part 2890X) or the Dual 4s Completer Pack (part 2997).
Charger
4s LiPo Balance Charger with iD^®
AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.

MODEL SPECS

Model Name:	XRT Ultimate
Model Type:	Monster Truck
Top Speed:	60+ mph with dual 4s LiPo batteries and optional gearing (sold separately)
Skill Level:	5
Scale:	X-Truck™
Weight:	21.55 pounds (9.79 kg)
Length:	31.41 inches (798 mm)
Width:	23.43 inches (595 mm)
Front Track:	23.43 inches (595 mm)
Track:	23.43 inches (595 mm)
Height:	10.15 inches (258 mm)

Wheelbase:	18.9 inches (480 mm)
Center Ground Clearance:	1.93 inches (49 mm)
Drivetrain:	Shaft-driven 4WD
Transmission:	Single speed
Differential Type:	Sealed, hardened steel bevel, limited slip
Gear Pitch:	1.0 metric pitch
Servo:	2085RL metal gear ultra-high-torque waterproof
Radio System:	TQi™ 2.4 GHz 2-channel transmitter with wireless module
Battery Compartment Specs:	185 mm X 51 mm X 44 mm

MOTOR SPECS

Motor Name:	Velineon^® 1200XL
Motor Type:	1275 Kv sensorless brushless
Motor Weight:	23.44 ounces (665 g)
Motor Length:	4.32 inches (110 mm)
Motor Diameter:	1.88 inches (48 mm)
Motor Shaft Size:	5 mm
Motor Connector Type:	6.5 mm bullet connectors

ESC SPECS

ESC Name:	Velineon^® VXL-8s
ESC Type:	Brushless
ESC Case Size:	2.23 inches (58 mm) / 2.83 inches (72 mm) / 1.81 inches (46 mm)
ESC Weight:	7.60 ounces (215.5 g)
Motor Connectors:	6.5 mm bullet connectors
Battery Connectors:	Traxxas High-Current Connectors
ESC Power Wire:	10 gauge Maxx^® Cable
