RRE007 Reflex Racing HV Mini Digital Servo (Reflex Racing)

Based on the AGFRC A06CLS V2 servo but with the more common 1/28 scale 20T Spline that comes in other servos like the GL line of servos and the V1 A06.  This is the perfect servo for your RX28 or other 2wd 1/28th scale kits.  The servo comes with a stealth all black wire leads and much shorter so that you can get that clean factory look.



Operating Voltage

4.8-8.4V



Operating Speed

0.075 sec/ 60* @4.8V

0.066 sec/ 60* @6.0V

0.058 sec/ 60* @7.4V

0.052 sec/ 60* @8.4V



Static Holding Torque

25 oz-in @4.8V

30 oz-in @6.0V

36 oz-in @7.4V

41 oz-in @8.4V



Size

20x8x17.8mm



Weight

7g



Connector

JST1.5- 45mm long
